Mean Well RSDH-150-12 (120W 12V)
SKU
RSDH-150-12
Authorized MEAN WELL
Stocking Distributor
$71.10
- Buy 5 for $67.70 each and save 5%
- Buy 10 for $64.70 each and save 9%
- Buy 20 for $62.80 each and save 12%
MEAN WELL Single Output Industrial DC-DC Converter, Enclosed Package, 120 Watts, Input Voltage Range: 250~1500VDC, Output Voltage: 12VDC, Output Current: 10A
More Details
The MEAN WELL RSDH-150-12 is a industrial, single output, DC-DC converter. This power supply can accept an input voltage between 250 VDC and 1500 VDC with a nominal input of 800 volts. The RSDH-150-12 has a 12 Volt Output at 10 amps (120 watts). The operating temperature is -40~+80°C and comes with several safety marks including DEKRA/EAC/CB/CE/UKCA. The RSDH-150-12, DC-DC converter, has a Enclosed package type and its dimensions are 191 (L) x 86 (W) x 41 (H) mm. If you have questions about this MEAN WELL DC-DC power supply please contact us through our web chat or call us (408-733-9090).
MEAN WELL RSDH-150-12 Features
View More
For specific information on the MEAN WELL RSDH-150-12 please view the datasheet
Other models in the RSDH-150 series: 250~1500Vdc in, 24Vdc out-RSDH-150-24;, 250~1500Vdc in, 32Vdc out-RSDH-150-32;, 250~1500Vdc in, 48Vdc out-RSDH-150-48;
| Price | $71.10 |
|---|---|
| Manufacturer | Mean Well |
| Application | Industrial (ITE) |
| Package Type | Enclosed |
| Power Output (W) | 120 |
| Nominal DC Input (VDC) | 800 |
| Input Voltage Range (VDC) | 250~1500 |
| Voltage - Output 1 (VDC) | 12 |
| Output Current | 10A |
| Length | 7.52in (191.00mm) |
| Width | 3.39in (86.00mm) |
| Height | 1.61in (41.00mm) |
| Number Outputs | 1 |
| Operating Temperature | -40C ~ 80C (with derating) |
| Country of Origin | China |
| Weight (lbs) | 1.810000 |
| Product Series | RSDH-150 |
Get Help Finding the Right Power Supply: Power Requirement Form
