Mean Well MPM-90-48ST (90W 48.0V)

SKU
MPM-90-48ST
Image at top has 5 yellow stars, below it is the red Mean Well logo. Image at top has 5 yellow stars, below it is the red Mean Well logo.

  Authorized MEAN WELL

  Stocking Distributor

$29.30
  • Buy 5 for $27.90 each and save 5%
  • Buy 10 for $26.60 each and save 9%
  • Buy 20 for $25.90 each and save 12%

Product images shown are for illustration purposes only and may not be an exact representation of the product.

MEAN WELL Single Output, Medical AC-DC Converter, Enclosed Package, 90.24 Watts, Input Voltage Range: 80~264VAC, Output Voltage: 48VDC, Output Current: 1.88A

More Details
The MEAN WELL MPM-90-48ST is a medical safety certified, single output, AC-DC power supply. The nominal output is 48 Volts DC at 1.88 amps, with a maximum power output of 90 watts. This power converter accepts an AC input voltage of 80~264 and has an efficiency rating of 93%. The MPM-90-48ST has an Enclosed package type with an operating temperature range of -30C to +80C. This AC-DC converter has no on board fan and its dimensions are 109 (L) x 52 (W) x 33.5 (H) mm. If you have questions about this MEAN WELL AC-DC power supply please contact us through our web chat or call us (408-733-9090).

MEAN WELL MPM-90-48ST Features

AC-DC Medical Enclosed Single output power supplyOutput: 48 volts, 1.88 amps, 90 wattsConnection Type: 3.43"x2.05" compact sizePCB chassis or screw terminal mounting version

View MoreMedical safety approved (2 x MOPP) according to ANSI / AAMI ES60601-1 and IEC / BS EN / EN60601-1Suitable for BF application with appropriate system considerationNo load power consumption<0.1WExtremely low leakage currentWide operating temp. range -30 ~ +80°CEMI Class B without additional componentsIsolation Class IIProtections: Short circuit / Overload / Over voltageNo minimum load requiredOperating altitude up to 4000 meters100W peak (10 sec.)3 year warranty

For specific information on the MEAN WELL MPM-90-48ST please view the datasheet

Other models in the MPM-90-ST series: 12 volt-MPM-90-12ST; 15 volt-MPM-90-15ST; 24 volt-MPM-90-24ST

More Information
Price$29.30
Weight (lbs)0.485100
ManufacturerMean Well
Package TypeEnclosed
IndustryMedical
ApplicationMedical
AC Input (VAC)80~264
Voltage - Output 1 (VDC)48
Output Current1.88A
Power Output (W)90
Height1.32in (33.50mm)
Length4.29in (109.00mm)
Width2.05in (52.00mm)
CoolingNo On Board Fan
Number Outputs1
Operating Temperature-30C ~ 80C (with derating)
Product SeriesMPM-90-ST
