Mean Well IRM-10-24
SKU
IRM-10-24
Authorized MEAN WELL
Stocking Distributor
$7.20
- Buy 5 for $6.90 each and save 4%
- Buy 10 for $6.60 each and save 8%
- Buy 20 for $6.40 each and save 11%
MEAN WELL Single Output, Industrial AC-DC Converter, On Board Package, 10.08 Watts, Input Voltage Range: 85~305VAC, Output Voltage: 24VDC, Output Current: 0.42A
More Details
The MEAN WELL IRM-10-24 is a industrial, single output, AC-DC power supply. The nominal output is 24 Volts DC at 0.42 amps, with a maximum power output of 10 watts. This power converter accepts an AC input voltage of 85~305 and has an efficiency rating of 82%. The IRM-10-24 has an On Board or Board Mount package type with an operating temperature range of -30C to +70C. This AC-DC converter has no on board fan and its dimensions are 45.7 (L) x 25.4 (W) x 21.5 (H) mm. If you have questions about this MEAN WELL AC-DC power supply please contact us through our web chat or call us (408-733-9090).
MEAN WELL IRM-10-24 Features
View More
For specific information on the MEAN WELL IRM-10-24 please view the datasheet
Other models in the IRM-10 series: 3.3 volt-IRM-10-3.3; 5 volt-IRM-10-5; 12 volt-IRM-10-12; 15 volt-IRM-10-15
| Price | $7.20 |
|---|---|
| Weight (lbs) | 0.088200 |
| Manufacturer | Mean Well |
| Package Type | On Board |
| Industry | Industrial |
| Application | Industrial (ITE) |
| AC Input (VAC) | 85~305 |
| Voltage - Output 1 (VDC) | 24.0 |
| Output Current | 0.42A |
| Power Output (W) | 10 |
| Height | 0.85in (21.50mm) |
| Length | 1.80in (45.70mm) |
| Width | 1.00in (25.40mm) |
| Cooling | No On Board Fan |
| Number Outputs | 1 |
| Operating Temperature | -30C ~ 70C (with derating) |
| Product Series | IRM-10 |
Get Help Finding the Right Power Supply: Power Requirement Form
