Mean Well IRM-03-5S
SKU
IRM-03-5S
Authorized MEAN WELL
Stocking Distributor
$6.10
- Buy 5 for $5.80 each and save 5%
- Buy 10 for $5.50 each and save 10%
- Buy 20 for $5.40 each and save 11%
MEAN WELL Single Output, Industrial AC-DC Converter, On Board Package, 3 Watts, Input Voltage Range: 85~305VAC, Output Voltage: 5VDC, Output Current: 600mA
More Details
The MEAN WELL IRM-03-5S is a industrial, single output, AC-DC power supply. The nominal output is 5 volts DC at 0.6 amps, with a maximum power output of 3 watts. This power converter accepts an AC input voltage of 85~305 and has an efficiency rating of 72%. The IRM-03-5S has an On Board or Board Mount package type with an operating temperature range of -30C to +85C. This AC-DC converter has no on board fan and its dimensions are 37 (L) x 24 (W) x 16 (H) mm. If you have questions about this MEAN WELL AC-DC power supply please contact us through our web chat or call us (408-733-9090).
MEAN WELL IRM-03-5S Features
View More
For specific information on the MEAN WELL IRM-03-5S please view the datasheet
Other models in the IRM-03 series: 3.3 volt-IRM-03-3.3; 5 volt-IRM-03-5; 9 volt-IRM-03-9; 12 volt-IRM-03-12; 15 volt-IRM-03-15; 24 volt-IRM-03-24; 3.3 volt-IRM-03-3.3S; 9 volt-IRM-03-9S; 12 volt-IRM-03-12S; 15 volt-IRM-03-15S; 24 volt-IRM-03-24S
| Price | $6.10 |
|---|---|
| Weight (lbs) | 0.066150 |
| Manufacturer | Mean Well |
| Package Type | On Board |
| Industry | Industrial |
| Application | Industrial |
| AC Input (VAC) | 85~305 |
| Voltage - Output 1 (VDC) | 5.0 |
| Output Current | 600mA |
| Power Output (W) | 3 |
| Height | 0.63in (16.00mm) |
| Length | 1.46in (37.00mm) |
| Width | 0.94in (24.00mm) |
| Cooling | No On Board Fan |
| Number Outputs | 1 |
| Operating Temperature | -30C ~ 85C (with derating) |
| Product Series | IRM-03 |
