Mean Well DDRH-30-15DR (30W 15.0V)
SKU
DDRH-30-15DR
$46.60
- Buy 5 for $44.30 each and save 5%
- Buy 10 for $42.40 each and save 9%
- Buy 20 for $41.20 each and save 12%
MEAN WELL Single Output Industrial DC-DC Converter, DIN Rail Package, 30 Watts, Input Voltage Range: 150~1500VDC, Output Voltage: 15VDC, Output Current: 2A
More Details
The MEAN WELL DDRH-30-15DR is a industrial, single output, DC-DC converter. This power supply can accept an input voltage between 150 VDC and 1500 VDC with a nominal input of 800 volts. The DDRH-30-15DR has a 15 volt output at 2 amps (30 watts). The operating temperature is -40~+80°C and comes with several safety marks including EAC/CE/UKCA. The DDRH-30-15DR, DC-DC converter, has a DIN Rail package type and its dimensions are 135 (L) x 70 (W) x 43.5 (H) mm. If you have questions about this MEAN WELL DC-DC power supply please contact us through our web chat or call us (408-733-9090).
MEAN WELL DDRH-30-15DR Features
View More
For specific information on the MEAN WELL DDRH-30-15DR please view the datasheet
Other models in the DDRH-30(DR) series: 150~1500Vdc in, 12Vdc out-DDRH-30-12DR;, 150~1500Vdc in, 24Vdc out-DDRH-30-24DR;, 150~1500Vdc in, 48Vdc out-DDRH-30-48DR;
| Price | $46.60 |
|---|---|
| Weight (lbs) | 0.683550 |
| Manufacturer | Mean Well |
| Package Type | DIN Rail |
| Industry | Industrial |
| Nominal DC Input (VDC) | 800 |
| Input Voltage Range (VDC) | 150~1500 |
| Voltage - Output 1 (VDC) | 15 |
| Output Current | 2A |
| Power Output (W) | 30 |
| Height | 1.71in (43.50mm) |
| Length | 5.31in (135.00mm) |
| Width | 2.76in (70.00mm) |
| Number Outputs | 1 |
| Operating Temperature | -40C ~ 80C (with derating) |
| Product Series | DDRH-30(DR) |
Get Help Finding the Right Power Supply: Power Requirement Form
