Mean Well DDR-15G-24
SKU
DDR-15G-24
Authorized MEAN WELL
Stocking Distributor
$20.10
- Buy 5 for $19.20 each and save 4%
- Buy 10 for $18.30 each and save 9%
- Buy 20 for $17.80 each and save 11%
MEAN WELL Single Output Industrial DC-DC Converter, DIN Rail Package, 15 Watts, Input Voltage Range: 9~36VDC, Output Voltage: 24VDC, Output Current: 0.63A
More Details
The MEAN WELL DDR-15G-24 is a industrial, single output, DC-DC converter. This power supply can accept an input voltage between 9 VDC and 36 VDC with a nominal input of 24 Volts. The DDR-15G-24 has a 24 Volt Output at 0.63 amps (15 watts). The operating temperature is -40~+85°C and comes with several safety marks including CE. The DDR-15G-24, DC-DC converter, has a DIN Rail package type and its dimensions are 54.5 (L) x 17.5 (W) x 90 (H) mm. If you have questions about this MEAN WELL DC-DC power supply please contact us through our web chat or call us (408-733-9090).
MEAN WELL DDR-15G-24 Features
View More
For specific information on the MEAN WELL DDR-15G-24 please view the datasheet
Other models in the DDR-15 series: 24Vdc in, 3.3Vdc out-DDR-15G-3.3;, 24Vdc in, 5Vdc out-DDR-15G-5;, 24Vdc in, 12Vdc out-DDR-15G-12;, 24Vdc in, 15Vdc out-DDR-15G-15;, 48Vdc in, 3.3Vdc out-DDR-15L-3.3;, 48Vdc in, 5Vdc out-DDR-15L-5;, 48Vdc in, 12Vdc out-DDR-15L-12;, 48Vdc in, 15Vdc out-DDR-15L-15;, 48Vdc in, 24Vdc out-DDR-15L-24;
| Price | $20.10 |
|---|---|
| Weight (lbs) | 0.150000 |
| Manufacturer | Mean Well |
| Package Type | DIN Rail |
| Industry | Industrial |
| Nominal DC Input (VDC) | 24 |
| Input Voltage Range (VDC) | 9~36 |
| Voltage - Output 1 (VDC) | 24.0 |
| Output Current | 0.63A |
| Power Output (W) | 15 |
| Height | 3.54in (90.00mm) |
| Length | 2.15in (54.50mm) |
| Width | 0.69in (17.50mm) |
| Number Outputs | 1 |
| Operating Temperature | -40C ~ 85C (with derating) |
| Product Series | DDR-15 |
Get Help Finding the Right Power Supply: Power Requirement Form
