Medical DC-DC Converters / Power Supplies
MEAN WELL Single Output Medical DC-DC Converter, DIP24 Package , On Board Package, 3 Watts, Input Voltage Range: 9~36VDC, Output Voltage: 5VDC, Output Current: 600mA
More Details
The MEAN WELL MDS03F-05 is a Medical, single output, DC-DC converter. This power supply can accept an input voltage between 9 VDC and 36 VDC with a nominal input of 24 Volts. The MDS03F-05 has a 5 volt output at 0.6 amps (3 watts). The operating temperature is -40~+90°C and comes with several safety marks including EAC/CE. The MDS03F-05, DC-DC converter, has a Board Mount package type and its dimensions are 31.8 (L) x 20.3 (W) x 12.2 (H) mm. If you have questions about this MEAN WELL DC-DC power supply please contact us through our web chat or call us (408-733-9090).$14.78MEAN WELL Single Output Medical DC-DC Converter, DIP24 Package , On Board Package, 3 Watts, Input Voltage Range: 9~36VDC, Output Voltage: 12VDC, Output Current: 250mA
More Details
The MEAN WELL MDS03F-12 is a Medical, single output, DC-DC converter. This power supply can accept an input voltage between 9 VDC and 36 VDC with a nominal input of 24 Volts. The MDS03F-12 has a 12 Volt Output at 0.25 amps (3 watts). The operating temperature is -40~+90°C and comes with several safety marks including EAC/CE. The MDS03F-12, DC-DC converter, has a Board Mount package type and its dimensions are 31.8 (L) x 20.3 (W) x 12.2 (H) mm. If you have questions about this MEAN WELL DC-DC power supply please contact us through our web chat or call us (408-733-9090).$14.78MEAN WELL Single Output Medical DC-DC Converter, DIP24 Package , On Board Package, 3 Watts, Input Voltage Range: 9~36VDC, Output Voltage: 15VDC, Output Current: 200mA
More Details
The MEAN WELL MDS03F-15 is a Medical, single output, DC-DC converter. This power supply can accept an input voltage between 9 VDC and 36 VDC with a nominal input of 24 Volts. The MDS03F-15 has a 15 volt output at 0.2 amps (3 watts). The operating temperature is -40~+90°C and comes with several safety marks including EAC/CE. The MDS03F-15, DC-DC converter, has a Board Mount package type and its dimensions are 31.8 (L) x 20.3 (W) x 12.2 (H) mm. If you have questions about this MEAN WELL DC-DC power supply please contact us through our web chat or call us (408-733-9090).$14.78MEAN WELL Single Output Medical DC-DC Converter, DIP24 Package , On Board Package, 3 Watts, Input Voltage Range: 18~75VDC, Output Voltage: 5VDC, Output Current: 600mA
More Details
The MEAN WELL MDS03G-05 is a Medical, single output, DC-DC converter. This power supply can accept an input voltage between 18 VDC and 75 VDC with a nominal input of 48 Volts. The MDS03G-05 has a 5 volt output at 0.6 amps (3 watts). The operating temperature is -40~+90°C and comes with several safety marks including EAC/CE. The MDS03G-05, DC-DC converter, has a Board Mount package type and its dimensions are 31.8 (L) x 20.3 (W) x 12.2 (H) mm. If you have questions about this MEAN WELL DC-DC power supply please contact us through our web chat or call us (408-733-9090).$14.78MEAN WELL Single Output Medical DC-DC Converter, DIP24 Package , On Board Package, 3 Watts, Input Voltage Range: 18~75VDC, Output Voltage: 12VDC, Output Current: 250mA
More Details
The MEAN WELL MDS03G-12 is a Medical, single output, DC-DC converter. This power supply can accept an input voltage between 18 VDC and 75 VDC with a nominal input of 48 Volts. The MDS03G-12 has a 12 Volt Output at 0.25 amps (3 watts). The operating temperature is -40~+90°C and comes with several safety marks including EAC/CE. The MDS03G-12, DC-DC converter, has a Board Mount package type and its dimensions are 31.8 (L) x 20.3 (W) x 12.2 (H) mm. If you have questions about this MEAN WELL DC-DC power supply please contact us through our web chat or call us (408-733-9090).$14.78MEAN WELL Single Output Medical DC-DC Converter, DIP24 Package , On Board Package, 3 Watts, Input Voltage Range: 18~75VDC, Output Voltage: 15VDC, Output Current: 200mA
More Details
The MEAN WELL MDS03G-15 is a Medical, single output, DC-DC converter. This power supply can accept an input voltage between 18 VDC and 75 VDC with a nominal input of 48 Volts. The MDS03G-15 has a 15 volt output at 0.2 amps (3 watts). The operating temperature is -40~+90°C and comes with several safety marks including EAC/CE. The MDS03G-15, DC-DC converter, has a Board Mount package type and its dimensions are 31.8 (L) x 20.3 (W) x 12.2 (H) mm. If you have questions about this MEAN WELL DC-DC power supply please contact us through our web chat or call us (408-733-9090).$14.78MEAN WELL Single Output Medical DC-DC Converter, SIP Package , On Board Package, 1 Watts, Input Voltage Range: 4.5~5.5VDC, Output Voltage: 3.3VDC, Output Current: 303mA
More Details
The MEAN WELL MDS01L-03 is a Medical, single output, DC-DC converter. This power supply can accept an input voltage between 4.5 VDC and 5.5 VDC with a nominal input of 5 volts. The MDS01L-03 has a 3.3 volt output at 0.303 amps (1 watts). The operating temperature is -40~+85°C and comes with several safety marks including UL/CE. The MDS01L-03, DC-DC converter, has a Board Mount package type and its dimensions are 19.558 (L) x 9.906 (W) x 12.446 (H) mm. If you have questions about this MEAN WELL DC-DC power supply please contact us through our web chat or call us (408-733-9090).$5.22 As low as $5.03MEAN WELL Single Output Medical DC-DC Converter, SIP Package , On Board Package, 1 Watts, Input Voltage Range: 4.5~5.5VDC, Output Voltage: 5VDC, Output Current: 200mA
More Details
The MEAN WELL MDS01L-05 is a Medical, single output, DC-DC converter. This power supply can accept an input voltage between 4.5 VDC and 5.5 VDC with a nominal input of 5 volts. The MDS01L-05 has a 5 volt output at 0.2 amps (1 watts). The operating temperature is -40~+85°C and comes with several safety marks including UL/CE. The MDS01L-05, DC-DC converter, has a Board Mount package type and its dimensions are 19.558 (L) x 9.906 (W) x 12.446 (H) mm. If you have questions about this MEAN WELL DC-DC power supply please contact us through our web chat or call us (408-733-9090).$5.22 As low as $5.03MEAN WELL Single Output Medical DC-DC Converter, SIP Package , On Board Package, 1 Watts, Input Voltage Range: 4.5~5.5VDC, Output Voltage: 12VDC, Output Current: 84mA
More Details
The MEAN WELL MDS01L-12 is a Medical, single output, DC-DC converter. This power supply can accept an input voltage between 4.5 VDC and 5.5 VDC with a nominal input of 5 volts. The MDS01L-12 has a 12 Volt Output at 0.084 amps (1 watts). The operating temperature is -40~+85°C and comes with several safety marks including UL/CE. The MDS01L-12, DC-DC converter, has a Board Mount package type and its dimensions are 19.558 (L) x 9.906 (W) x 12.446 (H) mm. If you have questions about this MEAN WELL DC-DC power supply please contact us through our web chat or call us (408-733-9090).$5.22 As low as $5.03MEAN WELL Single Output Medical DC-DC Converter, SIP Package , On Board Package, 1 Watts, Input Voltage Range: 4.5~5.5VDC, Output Voltage: 15VDC, Output Current: 67mA
More Details
The MEAN WELL MDS01L-15 is a Medical, single output, DC-DC converter. This power supply can accept an input voltage between 4.5 VDC and 5.5 VDC with a nominal input of 5 volts. The MDS01L-15 has a 15 volt output at 0.067 amps (1 watts). The operating temperature is -40~+85°C and comes with several safety marks including UL/CE. The MDS01L-15, DC-DC converter, has a Board Mount package type and its dimensions are 19.558 (L) x 9.906 (W) x 12.446 (H) mm. If you have questions about this MEAN WELL DC-DC power supply please contact us through our web chat or call us (408-733-9090).$5.22 As low as $5.03MEAN WELL Single Output Medical DC-DC Converter, SIP Package , On Board Package, 1 Watts, Input Voltage Range: 10.8~13.2VDC, Output Voltage: 5VDC, Output Current: 200mA
More Details
The MEAN WELL MDS01M-05 is a Medical, single output, DC-DC converter. This power supply can accept an input voltage between 10.8 VDC and 13.2 VDC with a nominal input of 12 Volts. The MDS01M-05 has a 5 volt output at 0.2 amps (1 watts). The operating temperature is -40~+85°C and comes with several safety marks including UL/CE. The MDS01M-05, DC-DC converter, has a Board Mount package type and its dimensions are 19.558 (L) x 9.906 (W) x 12.446 (H) mm. If you have questions about this MEAN WELL DC-DC power supply please contact us through our web chat or call us (408-733-9090).$5.22 As low as $5.03MEAN WELL Single Output Medical DC-DC Converter, SIP Package , On Board Package, 1 Watts, Input Voltage Range: 10.8~13.2VDC, Output Voltage: 12VDC, Output Current: 84mA
More Details
The MEAN WELL MDS01M-12 is a Medical, single output, DC-DC converter. This power supply can accept an input voltage between 10.8 VDC and 13.2 VDC with a nominal input of 12 Volts. The MDS01M-12 has a 12 Volt Output at 0.084 amps (1 watts). The operating temperature is -40~+85°C and comes with several safety marks including UL/CE. The MDS01M-12, DC-DC converter, has a Board Mount package type and its dimensions are 19.558 (L) x 9.906 (W) x 12.446 (H) mm. If you have questions about this MEAN WELL DC-DC power supply please contact us through our web chat or call us (408-733-9090).$5.22 As low as $5.03MEAN WELL Single Output Medical DC-DC Converter, SIP Package , On Board Package, 1 Watts, Input Voltage Range: 10.8~13.2VDC, Output Voltage: 15VDC, Output Current: 67mA
More Details
The MEAN WELL MDS01M-15 is a Medical, single output, DC-DC converter. This power supply can accept an input voltage between 10.8 VDC and 13.2 VDC with a nominal input of 12 Volts. The MDS01M-15 has a 15 volt output at 0.067 amps (1 watts). The operating temperature is -40~+85°C and comes with several safety marks including UL/CE. The MDS01M-15, DC-DC converter, has a Board Mount package type and its dimensions are 19.558 (L) x 9.906 (W) x 12.446 (H) mm. If you have questions about this MEAN WELL DC-DC power supply please contact us through our web chat or call us (408-733-9090).$5.22 As low as $5.03MEAN WELL Single Output Medical DC-DC Converter, SIP Package , On Board Package, 1 Watts, Input Voltage Range: 21.6~26.4VDC, Output Voltage: 5VDC, Output Current: 200mA
More Details
The MEAN WELL MDS01N-05 is a Medical, single output, DC-DC converter. This power supply can accept an input voltage between 21.6 VDC and 26.4 VDC with a nominal input of 24 Volts. The MDS01N-05 has a 5 volt output at 0.2 amps (1 watts). The operating temperature is -40~+85°C and comes with several safety marks including UL/CE. The MDS01N-05, DC-DC converter, has a Board Mount package type and its dimensions are 19.558 (L) x 9.906 (W) x 12.446 (H) mm. If you have questions about this MEAN WELL DC-DC power supply please contact us through our web chat or call us (408-733-9090).$5.22 As low as $5.03MEAN WELL Single Output Medical DC-DC Converter, SIP Package , On Board Package, 1 Watts, Input Voltage Range: 21.6~26.4VDC, Output Voltage: 12VDC, Output Current: 84mA
More Details
The MEAN WELL MDS01N-12 is a Medical, single output, DC-DC converter. This power supply can accept an input voltage between 21.6 VDC and 26.4 VDC with a nominal input of 24 Volts. The MDS01N-12 has a 12 Volt Output at 0.084 amps (1 watts). The operating temperature is -40~+85°C and comes with several safety marks including UL/CE. The MDS01N-12, DC-DC converter, has a Board Mount package type and its dimensions are 19.558 (L) x 9.906 (W) x 12.446 (H) mm. If you have questions about this MEAN WELL DC-DC power supply please contact us through our web chat or call us (408-733-9090).$5.22 As low as $5.03
