24 Volt Open Frame Power Supplies
At Bravo Electro, we understand the critical role that 24 Volt Open Frame power supplies play in powering industrial machinery, automation systems, and more. That's why we stock a comprehensive selection of high-quality solutions designed to meet the demands of various applications. Our range combines durability, efficiency, and affordability, ensuring that you get the best value for your investment.Read more
With our intuitive filtering system, you can quickly narrow down your options based on parameters such as input/output configuration, power rating, and safety certifications. Whether you're upgrading existing equipment or embarking on a new project, Bravo Electro provides the reliability and performance you need to succeed. Need help finding the right power supply for your requirements? No problem! Contact our friendly Power Experts by using our web chat, Power Requirement Form or call (408-733-9090). Other categories you might be interested in 24 Volt Enclosed power supplies, 24 Volt External power supplies, 24 Volt Medical power supplies, 24 Volt DIN Rail power supplies, 24 Volt Rack Mount power supplies, and 24 Volt On Board power supplies.
IPD Single Output AC-DC Converter, Open Frame Package, 70 Watts, Input Voltage Range: 85~264 VAC, Output Voltage: 24VDC, Output Current: 2.9A
More Details
The Integrated Power Designs REL-70-1006 is a single output, AC-DC power supply. The nominal output is rated for 24 volts at 2.9 amps (70 watts). It accepts an AC input range of 85~264 and has an efficiency rating of 0.87%. The REL-70-1006 is an Open Frame package type with an operating temperature range of 0C to +70C. This AC-DC converter has Medical and Industrial (ITE) safety certifications, no on board fan and its dimensions are 4.5 (L) x 2.5 (W) x 1.22 (H) inches. If you have questions about this IPD power supply please contact us through our web chat (lower right hand corner) or call us (408-733-9090).$87.44 As low as $81.83IPD Single Output AC-DC Converter, Open Frame Package, 185 Watts, Input Voltage Range: 85~264 VAC, Output Voltage: 24VDC, Output Current: 7.7A
More Details
The Integrated Power Designs REL-185-1006 is a single output, AC-DC power supply. The nominal output is rated for 24 volts at 7.7 amps (185 watts). It accepts an AC input range of 85~264 and has an efficiency rating of 0.87%. The REL-185-1006 is an Open Frame package type with an operating temperature range of 0C to +70C. This AC-DC converter has Medical and Industrial (ITE) safety certifications, no on board fan and its dimensions are 7 (L) x 4.25 (W) x 1.5 (H) inches. If you have questions about this IPD power supply please contact us through our web chat (lower right hand corner) or call us (408-733-9090).$159.99 As low as $149.73IPD Single Output AC-DC Converter, Open Frame Package, 150 Watts, Input Voltage Range: 85~264 VAC, Output Voltage: 24VDC, Output Current: 6.3A
More Details
The Integrated Power Designs REL-150-1006 is a single output, AC-DC power supply. The nominal output is rated for 24 volts at 6.3 amps (150 watts). It accepts an AC input range of 85~264 and has an efficiency rating of 0.87%. The REL-150-1006 is an Open Frame package type with an operating temperature range of 0C to +70C. This AC-DC converter has Medical and Industrial (ITE) safety certifications, no on board fan and its dimensions are 6 (L) x 3.83 (W) x 1.32 (H) inches. If you have questions about this IPD power supply please contact us through our web chat (lower right hand corner) or call us (408-733-9090).$130.23 As low as $121.88IPD Single Output AC-DC Converter, Open Frame Package, 110 Watts, Input Voltage Range: 85~264 VAC, Output Voltage: 24VDC, Output Current: 4.6A
More Details
The Integrated Power Designs REL-110-1006 is a single output, AC-DC power supply. The nominal output is rated for 24 volts at 4.6 amps (110 watts). It accepts an AC input range of 85~264 and has an efficiency rating of 0.87%. The REL-110-1006 is an Open Frame package type with an operating temperature range of 0C to +70C. This AC-DC converter has Medical and Industrial (ITE) safety certifications, no on board fan and its dimensions are 5 (L) x 3 (W) x 1.32 (H) inches. If you have questions about this IPD power supply please contact us through our web chat (lower right hand corner) or call us (408-733-9090).$110.51 As low as $103.42IPD Single Output AC-DC Converter, Open Frame Package, 400 Watts, Input Voltage Range: 85~264 VAC, Output Voltage: 24VDC, Output Current: 16.7A
More Details
The Integrated Power Designs NXT-400-1006 is a single output, AC-DC power supply. The nominal output is rated for 24 volts at 16.7 amps (400 watts). It accepts an AC input range of 85~264 and has an efficiency rating of 0.87%. The NXT-400-1006 is an Open Frame package type with an operating temperature range of 0C to +70C. This AC-DC converter has Medical and Industrial (ITE) safety certifications, no on board fan and its dimensions are 8 (L) x 3.9 (W) x 1.5 (H) inches. If you have questions about this IPD power supply please contact us through our web chat (lower right hand corner) or call us (408-733-9090).$370.30 As low as $346.56IPD Single Output AC-DC Converter, Open Frame Package, 350 Watts, Input Voltage Range: 85~264 VAC, Output Voltage: 24VDC, Output Current: 14.6A
More Details
The Integrated Power Designs NXT-325-1006 is a single output, AC-DC power supply. The nominal output is rated for 24 volts at 14.6 amps (350 watts). It accepts an AC input range of 85~264 and has an efficiency rating of 0.87%. The NXT-325-1006 is an Open Frame package type with an operating temperature range of 0C to +70C. This AC-DC converter has Medical and Industrial (ITE) safety certifications, no on board fan and its dimensions are 6 (L) x 3.9 (W) x 1.5 (H) inches. If you have questions about this IPD power supply please contact us through our web chat (lower right hand corner) or call us (408-733-9090).$240.01 As low as $224.63IPD Single Output AC-DC Converter, Open Frame Package, 225 Watts, Input Voltage Range: 85~264 VAC, Output Voltage: 24VDC, Output Current: 9.4A
More Details
The Integrated Power Designs NXT-225-1006 is a single output, AC-DC power supply. The nominal output is rated for 24 volts at 9.4 amps (225 watts). It accepts an AC input range of 85~264 and has an efficiency rating of 0.87%. The NXT-225-1006 is an Open Frame package type with an operating temperature range of 0C to +70C. This AC-DC converter has Medical and Industrial (ITE) safety certifications, no on board fan and its dimensions are 5 (L) x 3 (W) x 1.5 (H) inches. If you have questions about this IPD power supply please contact us through our web chat (lower right hand corner) or call us (408-733-9090).$179.18 As low as $167.69IPD Single Output AC-DC Converter, Open Frame Package, 175 Watts, Input Voltage Range: 85~264 VAC, Output Voltage: 24VDC, Output Current: 7.3A
More Details
The Integrated Power Designs NXT-175-1006 is a single output, AC-DC power supply. The nominal output is rated for 24 volts at 7.3 amps (175 watts). It accepts an AC input range of 85~264 and has an efficiency rating of 0.87%. The NXT-175-1006 is an Open Frame package type with an operating temperature range of 0C to +70C. This AC-DC converter has Medical and Industrial (ITE) safety certifications, no on board fan and its dimensions are 5 (L) x 3 (W) x 1.25 (H) inches. If you have questions about this IPD power supply please contact us through our web chat (lower right hand corner) or call us (408-733-9090).$162.85 As low as $152.41IPD Single Output AC-DC Converter, Open Frame Package, 100 Watts, Input Voltage Range: 85~264 VAC, Output Voltage: 24VDC, Output Current: 4.2A
More Details
The Integrated Power Designs NXT-100-1006 is a single output, AC-DC power supply. The nominal output is rated for 24 volts at 4.2 amps (100 watts). It accepts an AC input range of 85~264 and has an efficiency rating of 0.87%. The NXT-100-1006 is an Open Frame package type with an operating temperature range of 0C to +70C. This AC-DC converter has Medical and Industrial (ITE) safety certifications, no on board fan and its dimensions are 4.5 (L) x 2.5 (W) x 1 (H) inches. If you have questions about this IPD power supply please contact us through our web chat (lower right hand corner) or call us (408-733-9090).$109.30 As low as $102.29IPD Single Output AC-DC Converter, Open Frame Package, 80 Watts, Input Voltage Range: 85~264 VAC, Output Voltage: 24VDC, Output Current: 3.3A
More Details
The Integrated Power Designs GRN-80-1005 is a single output, AC-DC power supply. The nominal output is rated for 24 volts at 3.3 amps (80 watts). It accepts an AC input range of 85~264 and has an efficiency rating of 0.87%. The GRN-80-1005 is an Open Frame package type with an operating temperature range of 0C to +70C. This AC-DC converter has Medical and Industrial (ITE) safety certifications, no on board fan and its dimensions are 4.25 (L) x 2.5 (W) x 1 (H) inches. If you have questions about this IPD power supply please contact us through our web chat (lower right hand corner) or call us (408-733-9090).$66.84 As low as $62.55IPD Single Output AC-DC Converter, Open Frame Package, 60 Watts, Input Voltage Range: 85~264 VAC, Output Voltage: 24VDC, Output Current: 2.5A
More Details
The Integrated Power Designs GRN-60-1005 is a single output, AC-DC power supply. The nominal output is rated for 24 volts at 2.5 amps (60 watts). It accepts an AC input range of 85~264 and has an efficiency rating of 0.87%. The GRN-60-1005 is an Open Frame package type with an operating temperature range of 0C to +70C. This AC-DC converter has Medical and Industrial (ITE) safety certifications, no on board fan and its dimensions are 3 (L) x 2 (W) x 1 (H) inches. If you have questions about this IPD power supply please contact us through our web chat (lower right hand corner) or call us (408-733-9090).$44.67 As low as $41.81IPD Single Output AC-DC Converter, Open Frame Package, 110 Watts, Input Voltage Range: 85~264 VAC, Output Voltage: 24VDC, Output Current: 4.6A
More Details
The Integrated Power Designs GRN-110-1005 is a single output, AC-DC power supply. The nominal output is rated for 24 volts at 4.6 amps (110 watts). It accepts an AC input range of 85~264 and has an efficiency rating of 0.87%. The GRN-110-1005 is an Open Frame package type with an operating temperature range of 0C to +70C. This AC-DC converter has Medical and Industrial (ITE) safety certifications, no on board fan and its dimensions are 5 (L) x 3 (W) x 1.25 (H) inches. If you have questions about this IPD power supply please contact us through our web chat (lower right hand corner) or call us (408-733-9090).$84.22 As low as $78.82MEAN WELL Single Output, Industrial AC-DC Converter, Open Frame Package, 15 Watts, Input Voltage Range: 85~264VAC, Output Voltage: 24VDC, Output Current: 1A, Connection: Latching Crimp Connector
More Details
The MEAN WELL EPS-15-24 is a industrial, single output, AC-DC power supply. The nominal output is 24 Volts DC at 0.625 amps, with a maximum power output of 15 watts (some open frame power supplies require forced air to achieve maximum power output, check the datasheet for more details). It accepts an AC input voltage of 85~264 and has an efficiency rating of 83%. The EPS-15-24 has an Open Frame package type with an operating temperature range of -30C to +70C. It has no on board fan and its dimensions are 63.5 (L) x 45.7 (W) x 24 (H) mm. If you have questions about this MEAN WELL AC-DC power supply please contact us through our web chat or call us (408-733-9090).$7.40 As low as $6.60MEAN WELL Single Output, Industrial AC-DC Converter, Open Frame Package, 25 Watts, Input Voltage Range: 85~264VAC, Output Voltage: 24VDC, Output Current: 1A, Connection: Latching Crimp Connector
More Details
The MEAN WELL EPS-25-24 is a industrial, single output, AC-DC power supply. The nominal output is 24 Volts DC at 1.05 amps, with a maximum power output of 25 watts (some open frame power supplies require forced air to achieve maximum power output, check the datasheet for more details). It accepts an AC input voltage of 85~264 and has an efficiency rating of 88%. The EPS-25-24 has an Open Frame package type with an operating temperature range of -30C to +70C. It has no on board fan and its dimensions are 76.2 (L) x 50.8 (W) x 24 (H) mm. If you have questions about this MEAN WELL AC-DC power supply please contact us through our web chat or call us (408-733-9090).$11.60 As low as $10.20MEAN WELL Single Output, Industrial AC-DC Converter, Open Frame Package, 36 Watts, Input Voltage Range: 85~264VAC, Output Voltage: 24VDC, Output Current: 2A, Connection: Latching Crimp Connector
More Details
The MEAN WELL EPS-35-24 is a industrial, single output, AC-DC power supply. The nominal output is 24 Volts DC at 1.5 amps, with a maximum power output of 36 watts (some open frame power supplies require forced air to achieve maximum power output, check the datasheet for more details). It accepts an AC input voltage of 85~264 and has an efficiency rating of 89%. The EPS-35-24 has an Open Frame package type with an operating temperature range of -30C to +70C. It has no on board fan and its dimensions are 76.2 (L) x 50.8 (W) x 24 (H) mm. If you have questions about this MEAN WELL AC-DC power supply please contact us through our web chat or call us (408-733-9090).$12.00 As low as $10.60
